Application: Outdoor ; Sensor type: Passive Infra Red (PIR) and microwave (MW) ; Range: max. 12 x 15 m ; Detection angle: 100 ° ; Color: Gray ; Main features: Twilight Sensor Remote management ;
| Application: | Outdoor |
| Pyroelectric sensor: | Double |
| Sensor type: | Passive Infra Red (PIR) and microwave (MW) |
| Recommended installation height: | 2.4 m |
| Range: | max. 12 x 15 m |
| Detection angle: | 100 ° |
| Sensitivity adjustment: | 16-step - Control using the keys, Remote control |
| Alarm output: | NC |
| LED indication: | |
| Tamper output: | NC |
| Microwave frequency band: | 24 GHz |
| Pet immunity: | ≤ 20 kg |
| Antimask feature: |  |
| Alarm time: | 2 s |
| Maximal outputs load: | |
| Digital temperature compensation: | |
| Protection class (Grade): | EN50131-2-2 Grade 2 |
| Environmental class EN 50130-5: | IIIa |
| Power supply: | 12 V DC / 20 mA |
| Operation temp: | -40 °C ... 55 °C |
| Target speed range: | 0.3 ... 3 m/s |
| Color: | Gray |
| Main features: | |
| Weight: | 0.172 kg |
| Dimensions: | 138 x 65 x 58 mm |
| Manufacturer / Brand: | SATEL |
| Guarantee: | 2 years |
