Sensor type: Bimetallic ; Maximal power voltage: 250 V AC ; Relay maximal load: 10 A ; Temperature set range: 0 °C ... 60 °C ;
| Sensor type: | Bimetallic |
| Contact type: | NO - closed after exceeding the set temperature |
| Maximal power voltage: | 250 V AC |
| Relay maximal load: | 10 A |
| Temperature set range: | 0 °C ... 60 °C |
| Hysteresis: | 7 °C ± 4 °C |
| Operation temp: | -20 °C ... 80 °C |
| "Index of Protection": | IP20 |
| Mounting: | DIN rail 35 mm |
| Weight: | 0.042 kg |
| Dimensions: | 60 x 43 x 33 mm |
| Guarantee: | 2 years |
