Конвертер-Трансмиттер
The VGA-300 is designed for active transmission of the VGA signal via twisted-pair cable for the distance up to 300m. The transmitter converts the VGA signal, what enables its transmission via twisted-pair cable. Three pairs of wires allow to RGB signals transmission, the fourth pair - the synchronization of the transmission.
The device is equipped with overvoltage protection of the symmetrical line. The transmitter and receiver are sold as a set and a both devices need to be used for complete channel transmission.
Transmitter and receiver are in the kit.
|
Device type: |
|
|
Number of channels: |
1 VGA |
|
Power supply: |
12 V / 70 mA (power adapter not included) |
|
Video transmission range: |
max. 300 m |
|
Symmetrical socket impedance: |
100 Ω |
|
Connectors type: |
VGA Socket |
|
Symmetrical socket type: |
RJ-45 (8-pin, 4 pairs) Socket |
|
Weight: |
0.078 kg |
|
Dimensions: |
118 x 30 x 48 mm |
|
Device type: |
|
|
Number of channels: |
1 VGA |
|
Power supply: |
12 V / 170 mA (power adapter not included) |
|
Video transmission range: |
max. 300 m |
|
Symmetrical socket impedance: |
100 Ω |
|
Connectors type: |
VGA Socket female |
|
Symmetrical socket type: |
RJ-45 (8-pin, 4 pairs) Socket |
|
Weight: |
0.078 kg |
|
Dimensions: |
118 x 30 x 54 mm |
|
Main features: |
· Short-circuit protection · Signal correction |
|
Resolution: |
· 1920 x 1200 / 80 Hz @ 100 m · 1024 x 768 / 60 Hz @ 300 m |
