ELECTRIC STRIKE R3-12.11L
Ole hyvä ja kirjaudu sisään, jotta voimme ilmoittaa sinulle vastauksesta
Rated voltage: 11 V ± 1 V AC/DC ; Application: left-side door ;
| Rated voltage: | 11 V ± 1 V AC/DC |
| Current consumption: | 240 mA AC / 350 mA DC |
| Application: | left-side door |
| Ratched lock: |  |
| Memory function: | |
| Reverse action: | |
| Clearance adjustment: |  |
| Allowable thrust on the door at ratchet release: | 30 N |
| Allowable load of the door impacting the lock: | 3000 N |
| Allowable uninterrupted operation time: | unlimited |
| Weight: | 0.20 kg |
| Dimensions: | 20 x 28.5 x 90 mm |
| Guarantee: | 2 years |
