The SINGLE NO-NC CONTACT PUSH-BUTTON DD1A.01/11-SIMON54 is a reliable and versatile monostable push-button switch designed for flush mounting. It is part of the Simon 54 product series, suitable for Nature and Premium frames, and is ideal for use as a bell or signaling button in electrical installations. This device features a pictogram bell, white color (RAL 9003), and offers flexible mounting options with either claw or screw mounting. Its construction from non-halogen PC plastic ensures durability, while its IP20/IP44 rating (with frame seal) provides resistance to dust and water ingress. The push-button is equipped with screw terminal connectors and is backed by a 6-year guarantee from KONTAKT Simon.
Device type: | Single NO-NC Contact Push-Button (bell, monostable) |
Rated voltage: | 250 V AC |
Rated current: | 16 A (inductive load) |
Connectors type: | screw terminals |
Application: | Flush-mounted, Simon 54 product series, for Nature, Premium frames |
Backlight: | ![]() |
Assembly: | Claw or screw mounting |
Main features: | |
"Index of Protection": | IP20 / IP44 (using frame seal) |
Housing: | Non-halogen plastic, PC |
Color: | White (RAL 9003) |
Weight: | 0.056 kg |
Dimensions: | |
Manufacturer / Brand: | KONTAKT Simon |
Guarantee: | 6 years |
