WS-909 is an amplifier dedicated to 9-line multiswitch installations (HotBird + ASTRA); Inputs: 8x 950 MHz ... 2150 MHz, 1x 47 MHz ... 862 MHz, 1x DC 2.1/5.5mm socket (power) ; Outputs: 8x 950 MHz ... 2150 MHz, 1x 47 MHz ... 862 MHz ; SAT amplification (cable pre-correction): 20 dBi ... 30 dBi ; TV amplification (cable pre-correction): 20 dBi ; Maximal output level SAT: 115 dBµV ; Maximal output level TV: 116 dBµV ;
| Inputs: | |
| Outputs: | |
| SAT amplification (cable pre-correction): | 20 dBi ... 30 dBi |
| TV amplification (cable pre-correction): | 20 dBi |
| SAT Gain control: | 0 dB ... 20 dB |
| TV Gain control: | 0 dB ... 20 dB |
| Maximal output level SAT: | 115 dBµV |
| Maximal output level TV: | 116 dBµV |
| Pre-amplifiers powering: |  |
| Main features: | |
| Power supply: | |
| Weight: | 0.45 kg |
| Dimensions: | 170 x 115 x 40 mm |
| Manufacturer / Brand: | TELMOR |
| Guarantee: | 3 years |
Brand:
Telmor
