Frequency range: 87 MHz ... 790 MHz ; Number of inputs/outputs: 1 / 4 ; Gain : 20 dB / 27 dB ± 2 dB ;
| Frequency range: | 87 MHz ... 790 MHz |
| Number of inputs/outputs: | 1 / 4 |
| Input/output impedance: | 75 Ω |
| Connectors type: | "F" |
| Gain : | 20 dB / 27 dB ± 2 dB |
| Gain adjustment: | 0 dB ... 14 dB (+/- 1dB) |
| S/N ratio: | ≤ 5 dB ± 1 dB |
| Maximum output level: | 102 dBµV |
| IMA3 60dB: | 96 dBµV |
| IMA2 60dB: | 83 dBµV |
| Return loss: | 10 dB |
| Operation temp: | -25 °C ... 55 °C |
| Power supply: | 12 V DC / 250 mA |
| Weight: | 0.3 kg |
| Dimensions: | 124 x 88 x 27 mm |
| Manufacturer / Brand: | AMS |
| Guarantee: | 2 years |
Brand:
AMS
