Number of outputs: 8 pcs - programmable ; Outputs type: 8 pcs OC, 8 pcs Relay ; Tamper output; Load capacity of OC type programmable outputs: 50 mA ; Relay switching current: max. 2 A DC ; Relay switching voltage: max. 24 V DC ;
| Number of outputs: | 8 pcs - programmable |
| Outputs type: | |
| Tamper output: |  |
| Load capacity of OC type programmable outputs: | 50 mA / 12 V DC |
| Relay switching current: | max. 2 A DC |
| Relay switching voltage: | max. 24 V DC |
| Current consumption by active relay: | 16 mA |
| Current consumption (w/o OC type output load and w/o active relays): | 36 mA |
| Power supply: | 12 V DC / 160 mA (max) |
| Main features: | |
| Operation temp: | -10 °C ... 55 °C |
| Weight: | 0.09 kg |
| Dimensions: | 140 x 68 mm |
| Manufacturer / Brand: | SATEL |
| Guarantee: | 2 years |
Brand:
Satel
