Detection: | Vibrations |
Sensitivity adjustment: | ![]() |
Alarm signaling: | Signal to control panel |
Area covering: | 12.56 m² - Metal (circle 2 m radius centered on sensor mounting location) 50.24 m² - Concrete (circle 4 m radius centered on sensor mounting location) |
Environment class: | II |
Power supply: | 8 V ... 16 V DC, (typical 12V) / 5 mA (max) |
Main features: | |
Housing: | Metal |
Color: | Gray |
Operation temp: | -40 °C ... 70 °C |
Weight: | 0.22 kg |
Dimensions: | 89 x 89 x 22 mm |
Manufacturer / Brand: | Vanderbilt |
Guarantee: | 2 years |
