Support: Hikvision ; Operation way: Thermal imaging detector ; Detection range: 3 m ; Detection angle: 90 ° ; Sensor: Uncooled VOx microbolometer ; Matrix size: 160 x 120 px ; Lens: 1.9 mm ; Resolution: 1280 x 720 ; Temperature measurement range: -20 °C ... 200 °C ; Network interface: 2.4 GHz - Wi-Fi ; RS-485 interface; Color: White ; Power supply: 5 ... 16 V DC, PoE ;
| Support: | Hikvision |
| Operation way: | Thermal imaging detector |
| Detection range: | 3 m |
| Detection angle: | 90 ° |
| Alarm signaling: | Relay output |
THERMAL IMAGING CAMERA:
| Sensor: | Uncooled VOx microbolometer |
| Matrix size: | 160 x 120 px |
| Pixel pitch: | 17 µm |
| Thermal sensitivity (NETD): | ≤ 50 mK @ 25 °C F1.1 |
| Spectral range: | 8 µm ... 14 µm |
| Lens: | 1.9 mm |
| View angle: | 90 ° |
| Resolution: | 1280 x 720 - 720p , 704 x 576 640 x 480 352 x 288 320 x 240 |
| Image compression method: | H.265 / H.264 |
| Main stream frame rate: | 25 fps @ 720p |
| Temperature measurement range: | -20 °C ... 200 °C |
| Accuracy of temperature measurement: | ± 8 °C |
General information:
| Network interface: | 2.4 GHz - Wi-Fi IEEE 802.11 b/g/n |
| Security measures: | WEP 64/128-bit, WPA/WPA2, WPA-PSK/WPA2-PSK |
| WEB Server: | Built-in |
| Max. number of on-line users: | 20 |
| ONVIF: |  |
| Web browser access ports: | 80 |
| PC client access ports: | 8000 - iVMS-4200 application |
| ONVIF port: | 80 |
| Alarm inputs / outputs: | 0 / 1 |
| RS-485 interface: | |
| Memory card slot: | Micro SD card support up to 256GB |
| Main features: | |
| Recommended installation height: | max. 2.8 m |
| Color: | White |
| Power supply: | |
| Power consumption: | max. 3.5 W |
| Operation temp: | -10 °C ... 40 °C |
| Permissible relative humidity: | ≤ 95 % (non-condensing) |
| Weight: | 0.1 kg |
| Dimensions: | |
| Supported languages: | Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Finnish, French, Greek, Spanish, Dutch, Lithuanian, Latvian, German, Norwegian, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Italian |
| Manufacturer / Brand: | HIKMICRO |
| SAP Code: | 305401641 |
| Guarantee: | 10 years |
Brand:
Hikvision
