SWITCH POE IP-8-20-H 8-PORT ATTE

€339.64

(Включая налог 21%)

Задать вопрос

КОД: IP-8-20-H

Доступность: 1 шт.

Кол-во:

+ −

Минимальное количество для товара "SWITCH POE IP-8-20-H 8-PORT ATTE" 1.

Купить в один клик

Описание
Особенности

LAN ports: 2 x RJ45 10/100/1000 Base-TX - Uplink 8 x RJ45 10/100 Base-TX + PoE (802.3af/at) / Passive PoE ; Transmission speed: 10 / 100 Mbps : 8 LAN & PoE ports 10 / 100 / 1000 Mbps : 2 LAN port ; Maximal total power: 96 W ;

LAN ports:	2 x RJ45 10/100/1000 Base-TX - Uplink 8 x RJ45 10/100 Base-TX + PoE (802.3af/at) / Passive PoE
Management:
LED diodes:	Power, LAN
Transmission speed:	10 / 100 Mbps : 8 LAN & PoE ports 10 / 100 / 1000 Mbps : 2 LAN port
Maximal output power:	40 W @ Passive PoE - 1 ... 8 ports, 30 W @ PoE (802.3at) - 1 ... 8 ports, 15.4 W @ PoE (802.3af) - 1 ... 8 ports
Maximal total power:	96 W
Main features:	Pin numbers for RJ-45 connector : 1/2, 3/6 - Wires to data transmission ; 4/5, 7/8 - Power supply Possibility to connecting in cascade Efficiency : 92 % @ 90 W Built-in switching power supply : 48 V DC / 96 W PSU thermal protection Short-circuit protection Overload protection TAMPER switch indicating open the cover The ability to independently turn on and off the PoE power for each of the LAN 1 ... LAN 8 ports Electronic fuse independently for each PoE channel The modular design streamlines service tasks and enables quick and easy system expansion The raster system of module assembly facilitates the expansion of the device by further modules Main cable entries on the back of the enclosure "Index of Protection" : IP20
Power supply:	180 ... 240 V AC - Built-in switching power supply
Weight:	4.33 kg
Dimensions:	400 x 450 x 140 mm
Manufacturer / Brand:	ATTE
Guarantee:	3 years
