SWITCH POE DS-3E0318P-E/M(C) 16-PORT SFP Hikvision

€177.51

(Включая налог 21%)

Задать вопрос

КОД: DS-3E0318P-E/M(C)

Доступность: 3 шт.

Кол-во:

+ −

Купить в один клик

Описание
Особенности

LAN ports: 16 x RJ45 10/100 Base-T ( 16 x PoE (802.3af/at) ), 1 x port Combo: SFP (1000 Base-X) / RJ45 (10/100/1000 Base-T) - Uplink, 1 x RJ45 10/100/1000 Base-T - Uplink ; Transmission speed: 10 / 100 Mbps - 16 LAN & PoE ports, 1000 Mbps - Combo: RJ45/SFP - Uplink, 10 / 100 / 1000 Mbps - RJ45 (Uplink) ; Maximal total power: 130 W ;

LAN ports:	16 x RJ45 10/100 Base-T ( 16 x PoE (802.3af/at) ), 1 x port Combo: SFP (1000 Base-X) / RJ45 (10/100/1000 Base-T) - Uplink, 1 x RJ45 10/100/1000 Base-T - Uplink
Transmission speed:	10 / 100 Mbps - 16 LAN & PoE ports, 1000 Mbps - Combo: RJ45/SFP - Uplink, 10 / 100 / 1000 Mbps - RJ45 (Uplink)
Maximal output power:	30 W / port PoE
Maximal total power:	130 W
MAC addresses table:	8k
Management:
Operation modes:	Extend - 9 ... 16 ports : 300 m, 10 Mbps @ UTP cat. 5e, 6 Port Isolation - 1 ... 16 ports Watchdog PoE - 1 ... 16 ports
LED diodes:	Power, Link/Act, PoE, PoE Max, G1/G1-F, G2
Main features:	High priority ports : 1 ... 8 ports - Dedicated to video transmission Intelligent PoE power management - the device controls power consumption on individual ports PoE power mode : The device supports 8-pin power supply - wires 1-2(-), 3-6(+), 4-5(+), 7-8(-) Port isolation Watchdog function Possibility to mount to the wall Can be mounted in a Rack 19" cabinet
Certificates:	CE, RoHS, FCC, WEEE, REACH
Protections:	Overvoltage 6 kV
Housing:	Metal, Desktop
Power supply:	100 ... 240 V AC, 50 / 60 Hz
Power consumption:	max. 150 W
Operation temp:	0 °C ... 45 °C
Weight:	1.864 kg
Dimensions:	335 x 176 x 45 mm
Manufacturer / Brand:	Hikvision
SAP Code:	301802543
Guarantee:	3 years
