LAN ports: 8 x LAN & PoE / WAN ; WAN interface: 2 x WAN / LAN ; Transmission speed: 10/100/1000 Mbps ; Power supply PoE: PoE (802.3af/at), 75 W (total) ; Management interface: HPP - Hik-Partner Pro support ; Main features: Load balance, VPN networks: IPsec VPN, L2TP VPN ;
LAN ports: | 8 x LAN & PoE / WAN (RJ-45) |
WAN interface: | 2 x WAN / LAN (RJ-45) |
Transmission speed: | 10/100/1000 Mbps |
LED indicators: | System, Link/Act, PoE Max |
DDNS: | ![]() |
DHCP server: | ![]() |
USB port: | ![]() |
Firmware update: | ![]() |
Power supply PoE: | Power output - LAN ports : PoE (802.3af/at), 75 W (total) |
Protections: | |
Default IP address: | 192.168.9.1 |
Management interface: | |
Mobile phones support: | Configuration using the Hik-Partner Pro application |
Main features: | - maximum 4 WAN ports, |
Power supply: | 54 V DC / 1.48 A (power adapter included) |
Power consumption: | max. 80 W (at full load) |
Operation temp: | 0 °C ... 40 °C |
Permissible relative humidity: | 5 % ... 95 % (non-condensing) |
Weight: | 0.5 kg |
Dimensions: | 190 x 125 x 27 mm |
Manufacturer / Brand: | Hikvision |
SAP Code: | 317200310 |
Guarantee: | 3 years |
