Approvals |
LPCB / CE-CPR |
|
Operating voltage |
20V ~ 28V DC |
|
Operating temperature |
-10ﾟC to 55ﾟC |
|
Current parameters |
Standby: 23mA; Commission: 56mA; Alarm: 33mA |
|
Beam sensor sensitivity |
Level 1: 2.6dB high sensitivity |
|
Level 2: 3.8dB medium sensitivity |
|
|
Level 3: 5.8dB low sensitivity |
|
|
Beam pathway length |
Span 1: 8 to 20 meters short path (1x mirror reflector reuired) |
|
Span 2: 20 to 40 meters short path (1x mirror reflector reuired) |
|
|
Span 3: 40 to 70 meters normal path (4x mirror reflector reuired) |
|
|
Span 4: 70 to 100 meters long path (4x mirror reflector reuired) |
|
|
Beam path angle |
+/- 0.4ﾟDirectional |
|
Alignment guide |
Laser beam pointer |
|
Digital display guide |
Nixie tube |
|
LED indicator guide |
Red: Fire; Yellow: Fault; Green: Alignment |
|
Reset time |
Less than 2 second (power cut) |
|
Relay capacity [Fire/Fault] |
Normally open/ 2.0A; 30VDC |
|
Material / colour |
ABS / White |
|
Dimension / Weight |
L: 190.87 x W: 126.87 x H:91.96mm / 440gm |
|
Weight |
0.130 kg with base |
|
Accessories |
Mounting bracket, 4 x mirror reflector |
|
Protection rating |
IP30 [IP66 glue seal-for permanent fixing] indoor application |
|
Humidity |
0 to 95% RH, Non condensing |
