Technical Data Power
Voltage: 190-265VAC
CAR Charging Voltage: 14.6VDC/29.6VDC
AGM Charging Voltage: 14.6VDC/29.2VDC
MOTO Charging Voltage: 14.6VDC 1.5A
LiFePO4 Charging Voltage: 14.6VDC/29.2VDC
REPAIR Charging Voltage: 14.8VDC/29.6VDC
Holding Voltage: 13.8VDC/27.6VDC
Minimum Starting Voltage: 7VDC
Maximum output voltage: 29.6 VDC
Maximum power: 120 W
No-load consumption: 4 W
Maximum charging current 12 V: 10 A
Maximum charging current 24 V: 5 A
Recommended battery capacity: from 6 Ah to 200 Ah.
Overload protection: YES
Thermal protection: YES
Intrinsically safe contact: YES
Winter charging mode: YES
Summer charging mode: YES
Working temperature: 0 ° C +40 ° C
Efficiency: > 85%
Cooling: Active
Charging connector: cable with crocodile clips.
Cabinet: ABS
Protection class (IP): IP21.
Dimensions 158*95*62mm
