Technical data:
Rated capacity: 9Ah
Overall height: 100mm
Height: 94mm
Width: 65mm
Length: 151 mm
Weight: 1.75±3%
Internal resistance (at 25°C): 45 mΩ
Capacity: (40°C): 102%
Capacity (25°C): 100%
Capacity (0°C): 85%
Capacity (-15°C): 65%
Self-discharge (25°C) 3msc: 91% of rated capacity
Self-discharge (25°C) 6msc: 82% of rated capacity
Self-discharge (25°C) 12ms: 64% of rated capacity
Recommended operating temperature: 25°C ± 3°C
Operating Temperature Range - Discharge: -15°C to 50°C
Operating Temperature Range - Charging: -10°C to 50°C
Operating Temperature Range - Storage: -20°C to 50°C
Buffer charging voltage (25°C): 13.5-13.8V DC
Cyclic charge voltage (25°C): 14.4-14.7 VDC
Maximum charging current: 1.65A
Maximum discharge current: 55A
Estimated service life (25°C): 5-8 years
Operating Temperature Range - Charging: -10°C to 50°C
Operating Temperature Range - Storage: -20°C to 50°C
Buffer charging voltage (25°C): 13.5-13.8V DC
Cyclic charge voltage (25°C): 14.4-14.7 VDC
Maximum charging current: 1.65A
Maximum discharge current: 55A
Estimated service life (25°C): 5-8 years
