NORMALLY OPEN RELAY MODULE PK1-5-ZN DELTA
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
It can be used to increase maximal load of controller transistor output line and for galvanic isolation between output line and load point; Number of relay outputs: 1 ; Power supply: 5 ... 9 V DC ; Relay maximal load: 5 A (max), 30 V DC / 50 V AC ; Output: NO ; Main features: Mounting with self-adhesive bases, Protections : Overvoltage, Reverse polarity connection ;
| Number of relay outputs: | 1 |
| Power supply: | 5 ... 9 V DC |
| Current consumption: | 80 mA / 5 V DC |
| Relay maximal load: | 5 A (max), 30 V DC / 50 V AC (max) |
| Output: | NO |
| Application: | relay for electromagnetic lock/electric strike |
| Main features: | |
| Operation temp: | -40 °C ... 85 °C |
| Weight: | 0.02 kg |
| Dimensions: | 69 x 18 x 27 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 3 years |
Brand:
Delta
