Adapter type: |
Switching |
|
Power voltage: |
90 ... 264 V AC |
|
Output voltage: |
24 V DC |
|
Output voltage adjustment: |
· 23 V ... 27.6 V DC (buffer operation) · 20 V ... 27.6 V DC (battery mode) |
|
Maximal load: |
· 3.2 A - Temperature < 30 °C · 2.3 A - Temperature = 40 °C |
|
Battery charging current: |
0.2 A |
|
Output power: |
90 W |
|
Number of outputs: |
2 pcs |
|
Protections: |
· Short-circuit · Overvoltage · Overload · Reverse polarity connection · Discharge |
|
Adapter operation control: |
· AC input voltage presence indication · DC output voltage presence indication · Battery charging indication |
|
Housing type: |
DIN |
|
Weight: |
0.41 kg |
|
Dimensions: |
122 x 93 x 50 mm |
|
Manufacturer / Brand: |
PULSAR |
|
Guarantee: |
2 years |
Brand:
Pulsar
