BUFFERED SWITCHING POWER SUPPLY ADAPTER HPSG2-24V10A-D PULSAR

188.93
(Включая налог 21%)
HPSG2-24V10A-D
8 шт.
+
Input voltage: 200 V ... 240 V AC ; Output voltage: 22.0 V ... 27.6 V (buffer operation) ; Max. output current (total): 10 A ; Battery charging current: 1 A / 2 A / 4 A ; Number of outputs: ; Protections: Protection against deep discharge of the battery ;
Adapter type: Switching
Input voltage: 200 V ... 240 V AC
Output voltage: 22.0 V ... 27.6 V (buffer operation)
20.0 V ... 27.6 V (battery operation)
Max. output current (total): 10 A
Battery charging current: 1 A / 2 A / 4 A
Power: 276 W
Number of outputs:
Protections:
  • Short-circuit
  • Overload
  • Overvoltage
  • Overvoltage
  • Tamper - opening the cover
  • Protection against deep discharge of the battery
  • Battery output protection against short circuit and reverse polarity connection
  • Adapter operation control:
  • EPS FLT output - indicating AC power collapse
  • APS FLT output - No battery or fail battery
  • AC input voltage presence indication AC
  • DC output voltage presence indication DC
  • Battery fault indication
  • Dynamic battery test
  • Battery circuit continuity control
  • Battery voltage control
  • Battery charge and maintenance control
  • Main features:
  • Efficiency ≤ 87 %
  • START function for manual switch to the battery power supply
  • Cooling fan system
  • Supported norms:
  • EN 50131-6:2017, 1÷2, Grade 2
  • EN 60839-11:2013, 1÷2, Grade 2
  • PN-83/T-42106
  • CE-LVD: EN62368-1
  • "Index of Protection" : IP20
  • Place for battery: 12V/7Ah x 2, 12V/18Ah x 2
    Max. battery dimensions: 450  x 190  x 168 mm
    Operation temp. / Relative humidity: -10  ... 40 °C / 20  ... 90 %
    Weight: 6.9 kg
    Dimensions: 465  x 395  x 173 mm + 14 mm
    Manufacturer / Brand: PULSAR
    Guarantee: 2 years
    Brand:
    Pulsar
