Power voltage: 90 V ... 132 V AC, 180 V ... 264 V AC ; Output voltage: 12 V DC ; Output voltage adjustment: 11.4 ... 13.2 V ; Maximal load: 8.5 A ; Maximal current for single output: 1 A ; Output power: 102 W ; MTBF (Mean Time Between Faults): > 700000 h ; Number of video outputs: 8 pcs BNC socket ; Number of power outputs: 8 pcs ;
| Adapter type: | Switching |
| Power voltage: | selectable by switch |
| Output voltage: | 12 V DC |
| Output voltage adjustment: | 11.4 ... 13.2 V |
| Maximal load: | 8.5 A |
| Maximal current for single output: | 1 A |
| Output power: | 102 W |
| Protections: | |
| MTBF (Mean Time Between Faults): | > 700000 h |
| Number of video outputs: | 8 pcs BNC socket |
| Number of video inputs: | 8 pcs screw terminals |
| Number of power outputs: | 8 pcs Cable terminals |
| Standard: | |
| Type of fuses: | 8 x 1A/250V, 5/20mm, delayed |
| LEDs application: | |
| Max. current: | |
| Assembly: | Rack 19" |
| Housing: | Metal |
| Color: | Black |
| Operation temp. / Relative humidity: | -10 °C ... 55 °C / < 95 % |
| Weight: | 0.69 kg |
| Dimensions: | 483 x 44 x 122 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 5 years |
Brand:
Delta
