· 1/2.8” 2Megapixel STARVIS™ CMOS · Powerful 25x optical zoom · Starlight technology · 120dB true WDR, 3D DNR · Max. 25/30fps@1080P, 25/30/50/60fps@720P · IR distance up to 100m · IP66
|
Standard: |
AHD, HD-CVI, HD-TVI, PAL |
|
Sensor: |
1/2.8 " STARVIS™ CMOS |
|
Matrix size: |
2.1 Mpx |
|
Resolution: |
1920 x
1080 - 1080p |
|
Range of IR illumination: |
100 m |
|
Lens: |
4.8 ... 120 mm |
|
View angle: |
· 59 ° ... 2.4 ° |
|
Optical zoom: |
x 25 |
|
Digital zoom: |
x 16 |
|
Rotation speed depending on ZOOM level: |
Yes |
|
Auto IR illuminator: |
Adaptive adjusting of the IR illuminator power to the lens zoom and outdoor light conditions |
|
Horizontal rotation range: |
360 ° continuous |
|
Vertical rotation range: |
-15 ° ... 90 ° |
|
Rotation speed (manual control): |
0.1 °/s ... 200 °/s (horizontal) , |
|
Preset rotation speed: |
240 °/s
(horizontal) |
|
PTZ control: |
Via interface RS-485 |
|
Protocols: |
Pelco-D, Pelco-P, DH-SD (auto detection) |
|
S/N ratio: |
> 55 dB |
|
Video output: |
AHD / HD-CVI / HD-TVI / CVBS, 1 Vpp 75 Ω |
|
Audio: |
External microphone input |
|
Number of presets: |
300 |
|
Route settings: |
8 |
|
Horizontal scan: |
Yes |
|
Park action: |
Call the set function (tour, scan, etc.) after specified dwell time |
|
Alarm inputs / outputs: |
2 / 1 |
|
Main features: |
· WDR - 120 dB - Wide Dynamic Range · 2D-DNR / 3D-DNR - Digital Noise Reduction · ICR - Movable InfraRed filter · BLC/HLC - Back Light / High Light Compensation · Auto White Balance · 24 Configurable Privacy Zones |
|
OSD menu: |
Yes |
|
Power supply: |
12 V DC / 3000 mA |
|
Power consumption: |
≤ 20 W |
|
Housing: |
Speed Dome, Metal / Plastic |
|
Color: |
White + Black |
|
"Index of Protection": |
IP66 |
|
Vandal-proof: |
No |
|
Operation temp: |
-40 °C ... 70 °C |
|
Weight: |
3.70 kg (with bracket) |
|
Dimensions: |
155 x 350 x 255 mm (with bracket) |
|
Supported languages: |
English |
|
Manufacturer / Brand: |
DAHUA |
|
Guarantee: |
3 years |
