• 32-channel IP video recorder • Dual core processor • Operating system Embedded LINUX • Recording up to 12 megapixels • Input bandwidth up to 320 Mb / s • Synchronous playback of 16 channels in real time • Video outputs 2 HDMI, 1 VGA • Audio input / output - 1 RCA / 1 RCA • P2P support • Storage of 4 SATA HDDs up to 10 TB each • Video compression H.265 / H.264 / MJPEG / MPEG4 • Network: 2 RJ-45 ports (10/100 / 1000M) • Mobile platforms iPhone, iPad, Android • Monitoring: Web browsing, CMS and DMSS • 3D positioning with Dahua PTZ cameras • Alarm input / output: 16/6 • Interfaces: 1 x USB2.0 / 2 x USB3.0, RS232 • ONVIF Ver. 2.4 • AC power supply 100-240 V
|
Standard: |
TCP/IP |
|
Supported resolutions: |
max. 12 Mpx - 4000 x 3000 px |
|
Video outputs: |
· 2 pcs HDMI - The SPOT function is configured on the HDMI2 output · 1 pcs VGA |
|
Audio support: |
32 Channels - Audio from cameras |
|
Audio inputs: |
1 pcs Microphone, CINCH |
|
Audio outputs: |
1 pcs CINCH |
|
Image compression method: |
H.265 / H.264 / MPEG-4 / MJPEG |
|
Supported hard drives: |
4 x 10 TB SATA III + 1 eSATA |
|
Recording modes: |
Manual, Sensor, Motion detection, Schedule |
|
Network protocols: |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, ONVIF 2.4 |
|
External storage devices backup: |
Backup to USB drive (pendrive), eSATA |
|
Searching and playback the records: |
Records searching: by time and events type. Records playback: forward,
backward, fast, slow |
|
Bitrate: |
max. 320 Mb/s |
|
Network functions: |
Full support via network, Remote records copying, Web Server built-in |
|
ONVIF: |
2.4 |
|
Alarm inputs / outputs: |
16 pcs / 6 pcs - Relay output |
|
PTZ control: |
Yes |
|
Motion Detection: |
22 x 18 motion zones |
|
USB: |
1 pcs
USB 2.0 |
|
Intelligent Image Analysis: |
Yes |
|
Mouse support: |
Yes |
|
IR remote controller in the set: |
No |
|
Power supply: |
230 V AC |
|
Weight: |
4.39 kg |
|
Dimensions: |
440 x 413 x 75 mm |
