NVR4416-16P-I - 16 IP ch, 12MP, 200Mbps, 16 PoE, HDD SATA 4x 8TB, HDMI/VGA, Audio 1/1. Alarm 16/4, 1 x GbEau, 2 USB

Standard:

TCP/IP

Supported resolutions:

max. 8.3 Mpx, 4K UHD - 3840 x 2160 px

Video outputs:

1 pcs HDMI
1 pcs VGA

Audio support:

16 Channels - Audio from cameras

Audio inputs:

1 pcs Microphone, CINCH

Audio outputs:

1 pcs CINCH

Image compression method:

H.265+ / H.265 / H.264+ / H.264 / MJPEG

Supported hard drives:

4  x 8 TB SATA III

Recording modes:

Manual, Sensor, Motion detection, Schedule

Network protocols:

HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Center, IP Search, P2P, ONVIF

External storage devices backup:

Backup to USB drive (pendrive)

Searching and playback the records:

Records searching: by time and events type. Records playback: forward, backward, fast, slow
Advanced searching (to the one second accuracy)
All channels synchronous playback, Smart Search function

Bitrate:

max. 200 Mb/s

Network functions:

Full support via network, Remote records copying, Web Server built-in
max. 128 on-line users

ONVIF:

2.4

Alarm inputs / outputs:

16 / 4

PTZ control:

Yes

Motion Detection:

22  x 18 motion zones

USB:

1 pcs USB 2.0
1 pcs USB 3.0

Intelligent Image Analysis:

Yes

Mouse support:

Yes

IR remote controller in the set:

No

Main features:

·  Advanced peripheral protection functions: intrusion, crossing line with separate rules for vehicles and pedestrians,

·  Support for devices with the ANPR vehicle identification functions and face recognition,

·  Identification of the type of the observed object (human, animal, vehicle),

·  Face recognition and analysis in real time (up to 12 photos per second) :

• Comparison of faces with images from the database
• Face analysis: determination of sex, age and characteristic elements of appearance (glasses, facial hair, mask)
• Real-time search of people on the basis of given side information in the range corresponding to features recognized by artificial intelligence of the device
• Face bases can be used globally or locally for one video channel - depending on the need
• In the base other than face photography, can also be stored such information as: name, sex, date of birth, nationality, address, ID number

·  Recognition of people based on the characteristic elements of the outfit (type of clothes, clothes color, accessories)

·  Recognition of cars based on color, body type, license plate color and brand

·  Recognition of other vehicles not being cars

·  Intelligent object search based on a photo - the recorder allows to upload a picture of a person or vehicle to search for it on a camera recording

Switch PoE:

·  16-port PoE Switch built-in, 25.5 W / Channel - PoE (802.3af/at), max. 150 W (total)

·  ePoE - 800 m : 1 ... 8 ports

Power supply:

230 V AC

Weight:

4.82 kg

Dimensions:

440  x 411  x 76 mm
