• 8-ми канальный IP видеорегистратор • Двухъядерный процессор • Операционная система LINUX • Разрешение до 8 Мп • Пропускная способность до 80 Mб/с • Видеовыходы 1 HDMI, 1 VGA • Сжатие видео H.265/H.264 • Декодирование 4х1080Р/1х8 Мп (30 к/с) • Поддержка Easy4ip • Хранение 1 SATA HDD до 6 Тб • Сеть: RJ-45 порт (10/100M) • Поддержка IPC UPnP, 8 PoE портов • iPhone, iPad, Android • Аудиовход/выход -1/1 RCA • Интерфейсы 2 х USB2.0 • ONVIF Ver. 2.4 • Питание DC 48 В/ 2 A
|
Standard: |
TCP/IP |
|
Supported resolutions: |
max. 8.3 Mpx - 3840 x 2160 px, 4K UHD |
|
Video outputs: |
1 pcs
HDMI |
|
Audio support: |
8 Channels - Audio from cameras |
|
Audio inputs: |
1 pcs CINCH - External microphone input |
|
Audio outputs: |
1 pcs CINCH |
|
Image compression method: |
H.265, H.264 |
|
USB: |
2 pcs USB 2.0 |
|
Supported hard drives: |
1 x 6 TB SATA |
|
Recording modes: |
Manual, Motion Detection, Schedule |
|
Network protocols: |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, NTP, DHCP, DNS, DDNS, IP Filter, FTP, IP Search, ONVIF 2.4 |
|
External storage devices backup: |
Backup to USB drive (pendrive) |
|
Searching and playback the records: |
Records searching: by time and events type. Records playback: forward,
backward, fast, slow |
|
Bitrate: |
max. 80 Mb/s |
|
Network functions: |
Full support via network, Remote records copying, Web Server built-in |
|
Alarm inputs / outputs: |
No |
|
PTZ control: |
IP Speed Dome Cameras |
|
Motion Detection: |
22 x 18 motion zones - after motion detection records detected channels only |
|
Mouse support: |
Yes |
|
IR remote controller in the set: |
No |
|
Power supply: |
12 V DC / 2 A (power adapter included) |
|
Weight: |
0.82 kg |
|
Dimensions: |
260 x 225 x 48 mm |
