Specifications
|
Power Supply |
12V DC |
|
Current drain |
Standby 45 mA, Maximum 130 mA |
|
Alarm relay contacts withstand (RELAY1, RELAY2) |
15V, 30 mA |
|
Resistance of anti-masking relay contacts (MASK) |
15V, 30 mA |
|
Resistance of tamper switch contacts |
15V, 30 mA |
|
Warm-up time |
1 minute |
|
Alarm relay activation time |
2 seconds by default (programmable between 1 second to 99 minutes.). |
|
Anti-masking relay (MASK) activation time |
2 seconds at least and for as long as the masking exists. |
|
Anti-masking response time |
About 1 minute (Programmable from 1 to 99 cycles. Each cycle takes 3 seconds. |
|
Detection range |
Horizontal angle – up to 1800. Distance of up to 12 meters. |
|
Operating temperature |
-37 to + 700C |
FEATURES
- Selected horizontal detection angle – up to 180º.
- Multi-Zone includes 18 sensors:
– 6 PIR sensors.
– 3 Microwave sensors.
– 8 Anti-masking sensors.
– 1 Shock & Vibration sensor (Option). - The detector’s features can be programmed by Remote Control (can be purchased separately).
- The detector can be programmed by means of:
– The detector’s built-in keyboard.
– Remote Control (can be purchased separately).
– External control panel (bus/ communication). - Three different detection zones. For each
zone you can program the following:
– Detection range.
– PIR and Microwave detection sensitivity.
– Pulse Count.
– Anti-masking sensitivity. - Motion detection of certain direction.
- Relay activation time from 1 second to 99 minutes.
- Relay logics (N.C. / N.O.).
- Pet friendly.
- Option for tone effect upon each detection event.
- Automatic temperature and humidity compensation.
- Waterproof and resistant to bad weather conditions.
- Bracket Free (internal calibration).
