• Тип датчика: PIR(Пассивный инфракрасный датчик) + GBD(датчик разбития стекла) • Дальность обнаружения: 15м • Угол обзора: 100° • Режим PET: 25кг • Кронштейн: Не входит в комплект
|
Model |
LC-102PIGBS |
|
Operating Voltage |
8.2 to 16 Vdc |
|
Operating Current |
16.5 mA @ Standby / 16.2 mA @ Alarm / 22 mA @ Shock & Glass Alarm |
|
Temp Compensation |
Yes |
|
Alarm Output |
N.C. 28 Vdc 0.1 A with 10 Ohm series protection resistors |
|
Tamper Switch |
N.C. 28 Vdc 0.1 A with 10 Ohm series protection resistors – Open when cover is removed |
|
Alarm Time |
2 sec |
|
Pulse Count |
Auto |
|
Detector Start-Up Time |
60 sec |
|
Walk Detection Speed |
0.15 to 3.6 m/s |
|
Coverage Angle |
100° |
|
Operating Temperature |
From -20°C to +50°C |
|
Transient Immunity |
2.4 kV @ 1.2 joules |
|
RFI Immunity |
10 V/m plus 80% AM from 80 MHz to 1GHz |
|
Static Immunity |
8 kV contact, 15 kV air |
|
PET Immunity |
25 kg |
|
Dimensions |
118 x 62.5 x 41 mm |
|
Weight |
83 g |
