Standard: |
TCP/IP |
|
Sensor: |
1/3 " Progressive Scan CMOS |
|
Matrix size: |
4 Mpx |
|
Scanning system: |
Progressive |
|
Resolution: |
2688 x 1520 - 4 Mpx , |
|
Lens: |
2.8 mm |
|
View angle: |
· 93 ° · 94 ° |
|
Range of IR illumination: |
30 m |
|
Image compression method: |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
|
Bitrate: |
12
... 8448 kbps - H.265 |
|
Main stream frame rate: |
20 fps
@ 4 Mpx |
|
Network interface: |
10/100 Base-T (RJ-45) |
|
Network protocols: |
HTTP, HTTPS, TCP, ARP, RTSP, RTP, RTCP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/IPv6, QoS, UPnP, NTP, RTMP, SFTP, IEEE 802.1x, Multicast, ICMP, IGMP |
|
WEB Server: |
Built-in |
|
Max. number of on-line users: |
20 |
|
ONVIF: |
18.12 |
|
Mobile phones support: |
Port no.: 37777 or access by a cloud (P2P) · Android: Free application gDMSS Plus or DMSS · iOS (iPhone): Free application iDMSS Plus or DMSS |
|
Power supply: |
· PoE (802.3af), · 12 V DC / 500 mA |
|
Power consumption: |
≤ 6 W |
|
Housing: |
Compact - Aluminum |
|
Color: |
White |
|
"Index of Protection": |
IP67 |
|
Operation temp: |
-40 °C ... 60 °C |
|
Weight: |
0.4 kg |
|
Dimensions: |
Ø 70 x 165 mm |
|
Supported languages: |
Polish, English, Czech, French, Spanish Dutch, German, Portuguese, Russian, Italian |
|
Manufacturer / Brand: |
DAHUA |
|
Guarantee: |
3 years |
