Adapter type: |
Switching |
|
Power voltage: |
· 3 x 320 ... 600 V AC (3 phases), · 2 x 360 ... 600 V AC (2 phases) |
|
Output voltage: |
24 V DC |
|
Output voltage adjustment: |
24 ... 28 V DC |
|
Voltage tolerance: |
± 2 % |
|
Maximal load: |
40 A |
|
Output power: |
960 W |
|
Number of outputs: |
2 pcs |
|
Efficiency: |
> 92 % |
|
Housing type: |
DIN |
|
MTBF (Mean Time Between Faults): |
300000 hours |
|
Vibration resistance: |
IEC60068-2-6, 10 ... 500 Hz max. 3 G for 60 minutes |
|
Protections: |
· Short-circuit · Overvoltage · Overload protection |
|
Operation temp. / Relative humidity: |
-25 °C ... 65 °C / < 95 % |
|
Weight: |
2.62 kg |
|
Dimensions: |
255 x 121 x 117 mm |
|
Guarantee: |
2 years |
