Adapter type: |
Switching |
Power voltage: |
86 ... 264 V AC |
Output voltage: |
24 V DC |
Output voltage adjustment: |
22 ... 26 V |
Voltage tolerance: |
± 1 % |
Maximal load: |
2 A |
Output power: |
48 W |
Number of outputs: |
1 pcs |
Efficiency: |
87 % |
Housing type: |
DIN |
MTBF (Mean Time Between Faults): |
500000 hours |
Vibration resistance: |
IEC60068-2-6, 10 ... 150 Hz max. 5 G for 90 minutes |
Protections: |
· Short-circuit · Overvoltage · Overload protection |
Operation temp. / Relative humidity: |
-20 °C ... 75 °C / < 95 % |
Weight: |
0.21 kg |
Dimensions: |
32 x 101 x 100 mm |
Guarantee: |
2 years |
