Standard: |
HD-TVI |
|
Sensor: |
Progressive Scan CMOS |
|
Matrix size: |
3 Mpx |
|
Resolution: |
1920 x 1536 - 3 Mpx @ 18 fps |
|
Range of IR illumination: |
20 m |
|
IR illuminator power adjustment: |
Automatic |
|
Lens: |
3.6 mm |
|
View angle: |
· 68 ° |
|
S/N ratio: |
> 62 dB |
|
Video output: |
1 Vpp / 75 Ω - HD-TVI, BNC socket |
|
Main features: |
· WDR - 120 dB - Wide Dynamic Range · DNR - Digital Noise Reduction · EXIR - high-efficiency infrared LEDs technology, which evenly covers the whole plan of both central vantage points of the scene as well as the corners · ICR - Movable InfraRed filter · Auto White Balance · AGC - Automatic Gain Control · BLC - Back Light Compensation · Mirror - Mirror image |
|
OSD menu: |
OSD menu available via Hikvision HD-TVI recorder |
|
Power supply: |
12 V DC / 420 mA |
|
Power consumption: |
≤ 5 W |
|
Housing: |
Dome - Metal |
|
Color: |
White |
|
"Index of Protection": |
IP66 |
|
Operation temp: |
-40 °C ... 60 °C |
|
Weight: |
0.24 kg |
|
Dimensions: |
91 x 83 x 68 mm |
|
Supported languages: |
English |
|
Manufacturer / Brand: |
Hikvision |
|
Guarantee: |
2 years |
