• Full-color starlight • 120dB true WDR, 3DNR • Max. 30fps@1080P • HD/SD output switchable • Audio in interface, built-in mic • 3.6mm fixed lens • IP67, DC12V±30%
Technical Specifications:
Camera
• Image Sensor 1/2.8" CMOS
• Effective Pixels 1920(H)Ч1080(V), 2MP
• Scanning System Progressive
• Electronic Shutter Speed PAL: 1/4s~1/100,000s NTSC: 1/3s~1/100,000s
• Minimum Illumination 0.001Lux/F1.0, 30IRE
• S/N Ratio More than 65dB
• IR Distance N/A
• IR On/Off Control N/A
• IR LEDs N/A
Lens
• Lens Type Fixed lens / Fixed iris
• Mount Type Board-in
• Focal Length 3.6mm
• Max Aperture F1.0
• Angle of View H: 89.5°
• Focus Control N/A
• Close Focus Distance 1600mm (3500mm)
Pan/Tilt/Rotation
• Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotation: 0° ~ 360°
Video
• Resolution 1080P (1920Ч1080)
• Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P
• Video Output 1-channel BNC high definition video output / CVBS video output (DIP switch)
• Day/Night Color
• OSD Menu Multi-language
• BLC Mode BLC / HLC / WDR
• WDR 120dB
• Gain Control AGC
• Noise Reduction 2D/3D
• White Balance Auto / Manual
• Smart IR N/A
Interface
• Audio Interface 1ch in & Built-in Mic
Eelectrical
• Power Supply 12V DC ±30%
• Power Consumption Max. 2.4W (12V DC, IR on)
Environmental
• Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
• Start up should be done at above -40°C (-40°F)
• Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
• Ingress Protection & Vandal
• Resistance IP67
Construction
• Casing Aluminium
• Dimensions 244.1mmЧ90.4mmЧ90.4mm (9.61"Ч3.5"Ч23.5")
• Net Weight 0.75kg (1.65lb)
• Gross Weight 0.97kg (2.14lb)
