• Max 30fps@1080P • HD and SD output switchable • Built-in mic • 2.7-12mm motorized lens • Max. IR length 60m, Smart IR • IP67, DC12V
Camera
• Image Sensor 1/2.7" CMOS
• Effective Pixels 1920(H)Ч1080(V), 2MP
• Scanning System Progressive
• Electronic Shutter Speed PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
• Minimum Illumination 0.02Lux/F1.8, 30IRE, 0Lux IR on
• S/N Ratio More than 65dB
• IR Distance Up to 60m (197feet)
• IR On/Off Control Auto / Manual
• IR LEDs 2
Lens
• Lens Type Motorized lens / Fixed iris
• Mount Type Board-in
• Focal Length 2.7-12mm
• Max Aperture F1.8
• Angle of View H: 105.9°~33.4°
• Focus Control Motorized
• Close Focus Distance 200mm
• Pan/Tilt/Rotation Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360°
Video
• Resolution 1080P (1920Ч1080)
• Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P
• Video Output 1-channel BNC high definition video output / CVBS video output (Can switch)
• Day/Night Auto (ICR) / Manual
• OSD Menu Multi-language
• BLC Mode BLC / HLC / DWDR
• WDR DWDR
• Gain Control AGC
• Noise Reduction 2D
• White Balance Auto / Manual
• Smart IR Auto / Manual
Interface
• Audio Interface Built-in Mic
Eelectrical
• Power Supply 12V DC ±30%
• Power Consumption Max 8.2W (12V DC, IR on)
Environmental
• Operating Conditions -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH
• Start up should be done at above -30°C (-22°F)
• Storage Conditions -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH
Ingress Protection & Vandal
• Resistance IP67
Construction
• Casing Aluminium
• Dimensions F122mmЧ104mm (F4.8"Ч4.1")
• Net Weight 0.57kg (1.26lb)
• Gross Weight 0.72kg (1.59lb)
