TVI / AHD / CVI / CVBS
|
Angle Adjustment: |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
|||
|
Image Sensor: |
2.0 megapixel progressive scan CMOS |
|||
|
Signal System: |
PAL/NTSC |
|||
|
Effective Pixels: |
1920 (H) × 1080 (V) |
|||
|
Min. Illumination: |
0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
|||
|
Shutter Time: |
1/25(1/30) s to 1/50,000 s |
|||
|
Lens: |
2.8 - 12 mm @ F1.4 |
|||
|
Lens Mount: |
φ14 |
|||
|
Day& Night: |
IR cut filter with auto switch |
|||
|
Video Frame Rate: |
1080p@25fps/1080p@30fps |
|||
|
HD Video Output: |
1 Analog
HD output TVI / AHD / CVI / CVBS |
|||
|
Synchronization: |
Internal Synchronization |
|||
|
S/N Ratio: |
More than 62 dB |
|||
|
General |
||||
|
Operating Conditions: |
-40 °C - 60 °C (-40 °F - 140 °F) |
|||
|
Power Supply: |
12 VDC±15% |
|||
|
Power Consumption: |
Max. 4 W |
|||
|
Weather Proof: |
IP66 |
|||
|
IR Range: |
Up to 40m |
|||
|
Dimension: |
92mm×84.8mm×269.6mm (3.62”×3.34”×3.34”) |
|||
