• 1/3" progressive scan CMOS • 2560 × 1440@20fps • 2.8 mm to 12 mm varifocal lens • H.265+, H.265, H.264+, H.264 • Dual stream • 3D DNR • Up to 30 m IR range • IP67
|
Camera |
||||
|
Image Sensor: |
1/3" Progressive Scan CMOS |
|||
|
Min. Illumination: |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.02 Lux @ (F1.6, AGC ON) |
|||
|
Shutter time: |
1/3 s to 1/100, 000 s |
|||
|
Slow shutter: |
YES |
|||
|
Lens: |
2.8 mm to 12 mm |
|||
|
Lens Mount: |
φ14 |
|||
|
Adjustment Range: |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
|||
|
Day& Night: |
IR Cut Filter |
|||
|
Wide Dynamic Range: |
120 dB |
|||
|
Digital noise reduction: |
3D DNR |
|||
|
Compression Standard |
||||
|
H.265 Type: |
Main Profile |
|||
|
Video Compression: |
H.265/H.264/MJPEG |
|||
|
H.264 code profile: |
Baseline Profile/Main Profile/High Profile |
|||
|
Video bit rate: |
32Kbps~8Mbps |
|||
|
Image |
||
|
Max. Image Resolution: |
2560 x 1440 |
|
|
Frame Rate: |
50Hz:
20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1280, 1280 × 720) |
|
|
Sub Stream: |
50Hz:
25fps (640 × 480, 640 × 360, 320 × 240) |
|
|
Image Enhancement: |
BLC, 3D DNR |
|
|
Image Settings: |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
|
|
ROI: |
1 fixed region for main stream and sub-stream |
|
|
Day/Night Switch: |
Auto, scheduled, day, night |
|
|
Network |
||
|
General Function: |
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
|
|
Network Storage: |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
|
|
Alarm Trigger: |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
|
|
Protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
|
|
System Compatibility: |
ONVIF (Profile S, Profile G), ISAPI |
|
|
Interface |
|||||
|
Communication Interface: |
1 RJ45 10M/100M self-adaptive Ethernet port |
||||
|
On-board storage: |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
||||
|
Reset Button: |
Yes |
||||
|
General |
|||||
|
Operation Condition: |
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) |
||||
|
Power Supply: |
12 VDC ± 25%, PoE (802.3af Class3) |
||||
|
Power Consumption: |
12 VDC, 1 A, Max: 11 W |
||||
|
Weather Proof: |
IP67 |
||||
|
IR Range: |
Up to 30m |
||||
|
Dimensions: |
Camera: Ø 129.4 mm × 116.4 mm (5.1" × 4.6") |
||||
|
Weight: |
Camera: 560 g (1.2 lb.) |
||||
