• 1/2.8" HD progressive scan CMOS • 1920×1080resolution • 32×optical zoom • 120 dB true WDR(Wide Dynamic Range) • Up to 150m IR distance • 3D intelligent positioning • Switchable Turbo HDand CVBS outputs
|
Standard: |
AHD, HD-CVI, HD-TVI, CVBS |
|
Sensor: |
1/2.8 " Progressive Scan CMOS |
|
Matrix size: |
2.1 Mpx |
|
Resolution: |
1920 x
1080 - 1080p |
|
Range of IR illumination: |
150 m |
|
Lens: |
4.8 ... 153 mm |
|
View angle: |
· 54 ° ... 2 ° |
|
Optical zoom: |
x 32 |
|
Digital zoom: |
x 16 |
|
Rotation speed depending on ZOOM level: |
Yes |
|
Horizontal rotation range: |
360 ° continuous |
|
Vertical rotation range: |
-15 ° ... 90 ° |
|
Rotation speed (manual control): |
0.1 °/s ... 160 °/s (horizontal) , |
|
Preset rotation speed: |
160 °/s
(horizontal) |
|
PTZ control: |
Via interface RS-485 |
|
Protocols: |
Pelco-D, Pelco-P (auto detection) |
|
Video output: |
1 Vpp / 75 Ω - AHD / HD-CVI / HD-TVI / CVBS |
|
Audio: |
No |
|
Number of presets: |
256 |
|
Route settings: |
10 |
|
Horizontal scan: |
Yes |
|
Park action: |
Call the set function (tour, scan, etc.) after specified dwell time |
|
Alarm inputs / outputs: |
No |
|
Main features: |
· Intelligent 3D Positioning System · WDR ≥ 120 dB - Wide Dynamic Range · 3D-DNR - Digital Noise Reduction · EIS - Electronic Image Stabilization · IR illuminator optimization · BLC/HLC - Back Light / High Light Compensation · AGC - Automatic Gain Control · ICR - Movable InfraRed filter · Auto White Balance · Configurable Privacy Zones |
|
OSD menu: |
OSD menu available via Hikvision HD-TVI recorder |
|
Vandal-proof: |
No |
|
"Index of Protection": |
IP66 |
|
Power supply: |
24 V AC |
|
Power consumption: |
≤ 40 W |
|
Housing: |
Speed Dome, Metal |
|
Color: |
White |
|
Operation temp: |
-30 °C ... 65 °C |
|
Weight: |
4.5 kg |
|
Dimensions: |
Ø 220 x 353 mm |
|
Supported languages: |
Polish, English |
|
Manufacturer / Brand: |
Hikvision |
|
SAP Code: |
301205314 |
|
