In section: 100 m . Price for 1m when buying a whole roll ; Coaxial cable: TRISET ; Inner conductor: Ø 1.63 mm Cu ; Dielectric: Ø 7.11 mm (physical foam) ; Shield: Al/PET/Al ; Cable attenuation at 100m section: 13.2 dB @ 862 MHz ;
| In section: | 100 m . Price for 1m when buying a whole roll |
| Coaxial cable: | TRISET |
| Inner conductor: | Ø 1.63 mm Cu Wire |
| Dielectric: | Ø 7.11 mm (physical foam) |
| Shield: | Al/PET/Al - 9 µm / 23 µm / 9 µm |
| Braid: | 86 % Al wire |
| Outer coating: | Ø 10.2 mm PE + gel |
| Coating color: | Black |
| Resistance of the inner conductor for DC current: | 8.3 Ω/km |
| Capacity: | 52 pF/m |
| Dielectric resistance: | 2000 MΩ/km |
| Shortening wave coefficient: | 84 % |
| Impedance: | 75 Ω |
| Main features: | |
| Cable attenuation at 100m section: | 2.5 dB @ 47 MHz 4.1 dB @ 88 MHz 5.6 dB @ 174 MHz 6.5 dB @ 230 MHz 9.3 dB @ 470 MHz 13.2 dB @ 862 MHz 13.9 dB @ 950 MHz 21.0 dB @ 2150 MHz 21.6 dB @ 2400 MHz |
| Guarantee: | 2 years |
Brand:
Triset
