In section: 100 m . Price for 1m when buying a whole roll ; Inner conductor: Ø 2.7 mm Cu ± 0.02 mm Wire ; Outer coating: Ø 10.3 mm ± 0.20 mm PE ; Cable attenuation at 100m section: 20.0 dB @ 2000 MHz ;
| In section: | 100 m . Price for 1m when buying a whole roll |
| Inner conductor: | Ø 2.7 mm Cu ± 0.02 mm Wire |
| Dielectric: | Ø 7.2 mm Physical foam |
| Shield: | Foil - Al/PET |
| Braid: | 168 x Ø 0.15 mm Stranded wire CuSn |
| Impedance: | 50 Ω |
| Outer coating: | Ø 10.3 mm ± 0.20 mm PE |
| Main features: | |
| Cable attenuation at 100m section: | Temperature : 20 °C 2.3 dB @ 30 MHz 3.0 dB @ 50 MHz 4.9 dB @ 150 MHz 6.0 dB @ 220 MHz 8.7 dB @ 450 MHz 12.8 dB @ 900 MHz 17.0 dB @ 1500 MHz 18.8 dB @ 1800 MHz 20.0 dB @ 2000 MHz 22.7 dB @ 2500 MHz 37.6 dB @ 5800 MHz |
| Maximum transmitted power: | 3.36 kW @ 30 MHz 2.59 kW @ 50 MHz 1.47 kW @ 150 MHz 1.20 kW @ 220 MHz 0.82 kW @ 450 MHz 0.57 kW @ 900 MHz 0.43 kW @ 1500 MHz 0.39 kW @ 1800 MHz 0.36 kW @ 2000 MHz 0.32 kW @ 2500 MHz 0.20 kW @ 5800 MHz |
| Guarantee: | 2 years |
Brand:
Trilan
