Frequency range: 950 MHz ... 2150 MHz ; Signal level: -65 ... -25 dBm ; Display: TFT LCD ; Main features: DVB-S signals measurement / DVB-S2 ;
| Output and input: | F socket / F socket |
| Frequency range: | 950 MHz ... 2150 MHz - DVB-S / DVB-S2 signals measurement |
| Signal level: | -65 ... -25 dBm |
| LNB power supply: | 13/18 V, max. 500 mA |
| Switching between bandwidths: | 22 kHz |
| DiSEqC: | 1.0 |
| Modulation: | QPSK, 8PSK, 16APSK, 32APSK |
| Symbol rate: | 2 ... 45 Msps |
| Battery power supply: | 5 pcs AA (Batteries) |
| Power supply: | 13 V DC / 1 A |
| Display: | TFT LCD |
| Main features: | |
| Weight: | 0.14 kg |
| Dimensions: | 154 x 78 x 28 mm |
| Guarantee: | 2 years |
Brand:
Opticum
