It can be used to increase maximal load of controller transistor output line and for galvanic isolation between output line and load point; Number of relay outputs: 1 ; Power supply: 230 V AC ; Relay maximal load: 16 A / 250 V AC ; Output: 1 x NO/NC ; Manufacturer / Brand: ORNO ;
| Number of relay outputs: | 1 |
| Power supply: | 230 V AC |
| Current consumption: | 30 mA @ 230 V AC |
| Relay maximal load: | 16 A / 250 V AC (max) 16 A / 24 V DC (max) |
| Output: | 1 x NO/NC |
| Main features: | |
| Operation temp: | -20 °C ... 50 °C |
| Weight: | 0.07 kg |
| Dimensions: | 97 x 17 x 65 mm |
| Manufacturer / Brand: | ORNO |
| Guarantee: | 2 years |
Brand:
ORNO
