Support: | SUPLA |
Application: | Lighting control, switching devices on/off |
Number of inputs: | 4 |
Number of outputs: | 4 |
Number of pins: | 4 x NO/NC |
Rated voltage: | 195 V ... 255 V AC |
Total maximal current: | 5 A @ 250 V AC |
Maximal total load: | 1250 VA |
Maximal outputs load: | |
Connector type: | screw terminals |
Wireless: | Wi-Fi, 2.4 GHz - IEEE 802.11 b/g/n |
Mobile phones support: | |
Main features: | |
Housing: | Plastic, DIN, TS-35 rail mounting |
"Index of Protection": | IP20 |
Color: | Green |
Operation temp: | -10 °C ... 55 °C |
Weight: | 0.117 kg |
Dimensions: | 90 x 66 x 35 mm |
Manufacturer / Brand: | ZAMEL |
Guarantee: | 2 years |
