Standard: AHD / HD-CVI / HD-TVI - 8 Mpx 4K UHD, CVBS - PAL, NTSC ; Number of inputs: 8 pcs BNC ; Number of outputs: 16 pcs BNC ; Power supply: 7 ... 26 V DC ;
| Standard: | |
| Number of inputs: | 8 pcs BNC |
| Number of outputs: | 16 pcs BNC |
| Bandwidth: | 0 ... 120 MHz (-3dB) |
| Inputs impedance: | 75 Ω |
| Outputs impedance: | 75 Ω |
| Input protection: | ESD, IEC 61000-4-2, ±30kV contact, ±30kV air Lightning, IEC 61000-4-5, 12A (tP=8/20μs) |
| Outputs protection: | ESD, IEC 61000-4-2, ±30kV contact, ±30kV air Lightning, IEC 61000-4-5, 12A (tP=8/20μs) |
| Power supply: | 7 ... 26 V DC (power adapter not included) |
| Current consumption: | 120 mA @ 12 V DC |
| Gain : | 0 dB |
| Housing type: | 1 U Rack 19" |
| Dimensions: | 490 x 44 x 38 mm |
| Weight: | 0.34 kg |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 5 years |
Brand:
Delta
