Standard: AHD - 4 Mpx HD-CVI - 720p CVBS - PAL / NTSC ; Number of inputs: 1 pcs BNC ; Galvanic (optical) isolation between signal inputs and outputs: 1000 V peak ; Bandwidth: 33 MHz / 1 Vpp ; Power supply: 12 V DC / 90 mA ;
| Standard: | |
| Number of inputs: | 1 pcs BNC |
| Number of outputs: | 1 pcs BNC |
| Input impedance: | 75 Ω |
| Output impedance: | 75 Ω |
| Galvanic (optical) isolation between signal inputs and outputs: | 1000 V peak |
| Opto-isolation between power and signal inputs / outputs: | 1000 V peak |
| Gain adjustment: | -3 dB ... +3 dB |
| Bandwidth: | 33 MHz / 1 Vpp |
| Power supply: | 12 V DC / 90 mA |
| Weight: | 0.088 kg |
| Dimensions: | 120 x 62 x 30 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 3 years |
Brand:
Delta
