Number of inputs: 1 pcs BNC ; Galvanic (optical) isolation between signal inputs and outputs: 1000 V peak ; Bandwidth: 9 MHz / 1 Vpp ; Power supply: 12 V DC / 80 mA ;
| Standard: | CVBS - PAL / NTSC |
| Number of inputs: | 1 pcs BNC |
| Number of outputs: | 1 pcs BNC |
| Input impedance: | 75 Ω |
| Output impedance: | 75 Ω |
| Galvanic (optical) isolation between signal inputs and outputs: | 1000 V peak |
| Opto-isolation between power and signal inputs / outputs: | 1000 V peak |
| Gain adjustment: | -5 dB ... +5 dB |
| Bandwidth: | 9 MHz / 1 Vpp |
| Transmission error: | 0.75 % (f=3.58MHz, Vin=1Vpp) |
| Assembly: | To the wall |
| Power supply: | 12 V DC / 80 mA |
| Weight: | 0.095 kg |
| Dimensions: | 61 x 120 x 30 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 3 years |
Brand:
Delta
