Number of inputs: 1 pcs BNC socket ; Number of outputs: 1 pcs BNC plug ; Opto-isolation between inputs and outputs: 16 V DC ; Bandwidth: 180 MHz ;
| Standard: | |
| Device type: | Passive |
| Number of inputs: | 1 pcs BNC socket |
| Number of outputs: | 1 pcs BNC plug |
| Input impedance: | 75 Ω |
| Output impedance: | 75 Ω |
| Opto-isolation between inputs and outputs: | 16 V DC |
| Attenuation: | |
| Insertion loss: | 0.5 dB |
| Bandwidth: | 180 MHz |
| Power supply: |  |
| Operation temp: | -20 °C ... 55 °C |
| Weight: | 0.03 kg |
| Dimensions: | 60 x 28 x 22 mm |
| Guarantee: | 2 years |
Brand:
Delta CCTV
