VIDEO BALUN TRO-1/400
Войдите в учётную запись, чтобы мы могли сообщить вам об ответе
Device type: Active / Receiver ; Number of channels: 1 Video 1 DC ; Output voltage: max. 40 V DC / 1 A ;
| Input voltage: | max. 29 V AC / 1 A |
| Device type: | Active / Receiver |
| Number of channels: | 1 Video 1 DC |
| Coaxial socket voltage range 75Ω (CVBS): | 1 Vpp |
| Video transmission range: | max. 400 m UTP cat. 5e |
| Output voltage: | max. 40 V DC / 1 A |
| Video bandwidth: | 0 ... 50 MHz |
| Main features: | Delayed fuse 5x20, 2 A / 250 V |
| Symmetrical socket impedance: | 100 Ω |
| Connectors type: | BNC Socket Video Cable terminals DC |
| Symmetrical socket type: | RJ-45 (8-pin, 4 pairs) Socket |
| Power supply distance: | 1080 m @ 250 mA 260 m @ 750 mA 1600 m @ 250 mA 500 m @ 750 mA |
| Weight: | 0.100 kg |
| Dimensions: | 117 x 64 x 30 mm |
| Guarantee: | 3 years |
| Manufacturer / Brand: | DELTA |
