Sensor: Uncooled VOx microbolometer ; Matrix size: 256 x 192 px ; View angle: 51 ° ; Resolution: 1280 x 960, 1024 x 768 px ; Sensor: 1/2.7 " Progressive Scan CMOS ; Matrix size: 4 Mpx ; View angle: 71 ° ; Resolution: 2336 x 1752 - 4 Mpx ; RS-485 interface; Alarm inputs / outputs: 1 / 1 ; Audio: Bi-directional audio streaming support ; Power supply: PoE (802.3af), 12 V DC ;
| Sensor: | Uncooled VOx microbolometer |
| Matrix size: | 256 x 192 px |
| Pixel pitch: | 12 µm |
| Thermal sensitivity (NETD): | < 50 mK @ F1.0 |
| Spectral range: | 8 µm ... 14 µm |
| Color palettes: | 18 |
| Lens: | 3.5 mm |
| View angle: | 51 ° |
| Digital zoom: | x 16 |
| Resolution: | 1280 x 960 - 960p , 1024 x 768 px , 640 x 480 px , 256 x 192 px |
VIDEO CAMERA:
| Sensor: | 1/2.7 " Progressive Scan CMOS |
| Matrix size: | 4 Mpx |
| Scanning system: | Progressive |
| Lens: | 4 mm |
| View angle: | 71 ° |
| Min. illumination: | 0.05 Lux (color) 0.005 Lux (B/W) |
| Range of IR illumination: | 30 m |
| Resolution: | 2336 x 1752 - 4 Mpx 1920 x 1080 - 1080p 1280 x 720 - 720p 704 x 576 - D1 |
General information:
| Standard: | TCP/IP |
| Video output: |  |
| RS-485 interface: |  |
| Memory card slot: | Micro SD memory cards up to 256GB support (possible local recording) |
| Image compression method: | H.265 / H.264 / MJPEG |
| Alarm inputs / outputs: | 1 / 1 |
| Audio: | |
| Main stream frame rate: | 25 fps @ 1280 x 960 25 fps @ 4 Mpx |
| Network interface: | 10/100 Base-T (RJ-45) |
| Network protocols: | HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/IPv6, SNMP, QoS, UPnP, NTP |
| WEB Server: | Built-in |
| Max. number of on-line users: | 10 |
| ONVIF: | 20.12 |
| Default IP address: | 192.168.1.108 |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| ONVIF port: | 80 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Main features: | |
| Power supply: | |
| Power consumption: | ≤ 14 W |
| Housing: | Compact - Metal |
| Color: | White |
| "Index of Protection": | IP67 |
| Operation temp: | -30 °C ... 50 °C |
| Dimensions: | 206 x 91 x 90 mm |
| Weight: | 0.82 kg |
| Supported languages: | Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Turkish, Italian |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 3 years |
Brand:
Dahua
