Sensor: 1/2.8 " STARVIS™ CMOS ; Matrix size: 2.1 Mpx ; Resolution: 1920 x 1080 - 1080p ; View angle: 106 ° ... 35 ° ; Optical zoom: x 3 ; Range of IR illumination: 15 m ; Rotation speed (manual control): 0.1 °/s ... 70 °/s (horizontal) 0.1 °/s ... 30 °/s (vertical) ; Image compression method: H.265 ; Memory card slot: Micro SD memory cards up to 256GB support (possible local recording) ; Audio: Microphone built-in, External microphone input, Audio output ; Power supply: PoE (802.3af), 12 V DC ;
| Standard: | TCP/IP |
| Sensor: | 1/2.8 " STARVIS™ CMOS |
| Matrix size: | 2.1 Mpx |
| Resolution: | 1920 x 1080 - 1080p 1280 x 720 - 720p |
| Scanning system: | Progressive |
| Lens: | 2.8 ... 8.1 mm |
| View angle: | 106 ° ... 35 ° (manufacturer data) 100 ° ... 46 ° (our tests result) |
| Optical zoom: | x 3 |
| Digital zoom: |  |
| Range of IR illumination: | 15 m |
| S/N ratio: | > 50 dB (AGC off) |
| Video output: | |
| Rotation speed (manual control): | 0.1 °/s ... 70 °/s (horizontal) 0.1 °/s ... 30 °/s (vertical) |
| Preset rotation speed: | max. 80 °/s (horizontal) max. 40 °/s (vertical) |
| Horizontal rotation range: | 0 ° ... 355 ° - Rotation of the head is limited by stops |
| Vertical rotation range: | 5 ° ... 90 ° |
| RS-485 interface: | |
| Number of presets: | 300 |
| Horizontal scan: |  |
| Route settings: | 8 |
| Image compression method: | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Bitrate: | 448 ... 8192 kbps |
| Alarm inputs / outputs: | |
| Main stream frame rate: | 25 fps - 1080p |
| Memory card slot: | Micro SD memory cards up to 256GB support (possible local recording) |
| Network interface: | 10/100 Base-T (RJ-45) |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, UPnP, ICMP, IGMP, RTP, SNMP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, Bonjour, IEEE 802.1x |
| WEB Server: | Built-in, NVR compliance |
| Max. number of on-line users: | 20 |
| ONVIF: | 16.12 |
| Audio: | |
| Mobile phones support: | Port no.: 37777 or access by a cloud (P2P) |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Default IP address: | 192.168.1.108 |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| Mobile client access ports: | 37777 |
| ONVIF port: | 80 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Main features: | |
| Power supply: | |
| Power consumption: | ≤ 10.5 W |
| Housing: | Speed Dome Metal, Plastic |
| Color: | Black + White |
| "Index of Protection": | IP66 |
| Operation temp: | -30 °C ... 60 °C |
| Weight: | 0.51 kg |
| Dimensions: | Ø 128 x 63 mm |
| Supported languages: | English, Polish |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 5 years |
Brand:
Dahua
