NVR equipped with advanced functions of intelligent image analysis; Supported resolutions: max. 32 Mpx ; Audio support: 64 Channels ; Image compression method: H.265+ ; Supported hard drives: 8 x 20 TB SATA III + 1 x eSATA ; Alarm inputs / outputs: 16 / 8 ; Main features: Support for devices with the ANPR vehicle identification functions and face recognition, Face recognition and analysis in real time (up to 16 photos per second) ;
| Standard: | TCP/IP |
| Supported resolutions: | max. 32 Mpx |
| Video outputs: | 2 pcs HDMI 4K 2 pcs VGA |
| Audio support: | 64 Channels - Audio from cameras |
| Audio inputs: | 1 pcs CINCH |
| Audio outputs: | 2 pcs CINCH |
| Network interface: | 2 x RJ-45 10/100/1000 Base-TX |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| USB: | 2 pcs USB 2.0 2 pcs USB 3.0 |
| Supported hard drives: | 8 x 20 TB SATA III + 1 x eSATA Possibility of operation the disks in RAID 0/1/5/6/10 array |
| Recording modes: | Manual, Sensor, Motion detection, Schedule |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, P2P, Auto Register, ONVIF 21.12 |
| External storage devices backup: | Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: | Records searching: by time and events type. Records playback: forward, backward, fast, slow Advanced searching (to the one second accuracy) max. 32 channel synchronous playback |
| Bitrate: | max. 384 Mbps |
| Network functions: | Full support via network, Remote records copying, Web-Server built-in max. 128 on-line users |
| Mobile phones support: | Port no.: 37777 or access by a cloud (P2P) See how to configure the P2P function in Dahua recorders and how to enable the mobile application |
| Default IP address: | 192.168.1.108 |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| Mobile client access ports: | 37777 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Alarm inputs / outputs: | 16 / 8 |
| PTZ control: | RS-485, PELCO-D/P IP Speed Dome Cameras |
| RS-232 interface: |  |
| Motion Detection: | |
| Intelligent Image Analysis: | |
| Mouse support: | |
| IR remote controller in the set: |  |
| Main features: |
|
| Power supply: | 100 ... 240 V AC @ 50 / 60 Hz |
| Weight: | 6.35 kg |
| Dimensions: | 440 x 458 x 89 mm - RACK 19", 2U |
| Supported languages: | Polish, English, Bulgarian, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Slovenian, Serbian, Swedish, Hungarian, Italian |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 3 years |
Brand:
Dahua
