• Видеоформаты H.265+/H.265/H.264+/H.264 • Интеллектуальная аналитика на основе алгоритма глубокого обучения • Защита периметра до 4 каналов • До 4 каналов распознавания лиц для видеопотока • До 8 каналов распознавания лиц для изображения лица • До 32-канальных входов для IP-камер • Возможность декодирования до 32 каналов 1080p
- Intelligent Analytics
- AI by Device
- AI by Camera
- Engine
- Facial Recognition
- Facial Detection and Analytics Face picture comparison, human face capture, face picture search
- Face Attributes
- Face Picture Library Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)
- Face Picture Comparison (Captured from Camera) 4-ch face picture comparison alarm
- Facial Detection and Analytics Performance 1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
- Motion Detection 2.0
- By Device 16-ch
- By Camera
- Perimeter Protection
-
By Device
Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;
Up to 12 rules in total;Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;
Up to 12 rules in total;Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;
Up to 12 rules in total
- By Camera
- ANPR
- By Camera
- Vehicle Attributes
- Plate Attributes
- Video and Audio
-
IP Video Input
16-ch
Up to 12 MP resolution
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
- Incoming Bandwidth 160 Mbps
- Outgoing Bandwidth 256 Mbps
- HDMI 1 Output 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output
- HDMI 2 Output 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output
-
VGA Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
HDMI1/VGA simultaneous output
- Video Output Mode
- CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- Audio Output 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Decoding
- Decoding Format H.265+/H.265/H.264+/H.264/MPEG4
-
Recording Resolution
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
- Synchronous Playback 16-ch
- Live View Window Division 1/2/4/6/8/9/16
- Aux Port Window Division 1/2/4/6/8/9/16
- Decoding Capability 16-ch @ 1080p (30 fps)
- Dual-Stream Recording Support
- Stream Type Video, Video & Audio
- Audio Compression G.711ulaw/G.711alaw/G.722/G.726/MP2L2
- Network
- Network Interface 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- Remote Connection 128
- Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- API
- Compatible Browser
- Auxiliary Interface
- Serial Interface RS-485 (half-duplex), RS-232, Keyboard
- SATA 4 SATA interfaces supporting hot-plug
- Capacity Up to 10 TB capacity for each disk
- eSATA 1 eSATA interface
- Alarm In/Out 16/4
- USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- Ctrl 12V
- DC 12V
