Third-party network cameras supported • Up to 12 Megapixels resolution recording • Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160) resolution • 8/16-ch network cameras can be connected with 80M/160M incoming bandwidth• Up to 2 SATA interfaces • Plug & Play with up to 16 independent PoE network interfaces • Support dual-os to ensure high reliablility of system running •Support various VCA detection alarm and VCA search •Support H.265/H.264/MPEG4 video formats
|
ideo/Audio Input |
||
|
IP video input: |
| |
32-ch |
|
Two-way audio input: |
| |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
|
Two-way Audio: |
| |
1-ch, RCA (2.0 Vp-p, 1 k Ω) |
|
Network |
||
|
Incoming bandwidth: |
| |
256Mbps |
|
Outgoing bandwidth: |
| |
256Mpbs |
|
Remote connection: |
| |
128 |
|
Video/Audio Output |
||
|
HDMI Output: |
| |
1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
|
Recording Resolution: |
| |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Audio Output: |
| |
1-ch, RCA (Linear, 1kΩ) |
|
Synchronous Playback: |
| |
16-ch |
|
VGA Output: |
| |
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
|
Decoding |
||
|
Live view / Playback: |
| |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Capability: |
| |
4-ch @ 4K, or 16ch @ 1080p |
|
Hard Disk |
||
|
SATA: |
| |
2 SATA interfaces for 2 HDDs |
|
Capacity: |
| |
Up to 6TB capacity for each HDD |
|
External Interface |
||
|
Network Interface: |
| |
1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
|
USB Interface: |
| |
Front panel: 1 × USB 2.0 |
|
Alarm In: |
| |
4-ch |
|
Alarm Out: |
| |
1-ch |
|
POE |
||
|
Interface: |
| |
16 independent 10/100 Mbps PoE Ethernet interfaces |
|
Max. Power: |
| |
200W |
|
Supported Standard: |
| |
AF and AT |
|
General |
||
|
Power Supply: |
| |
100 to 240 VAC, 50 to 60 Hz |
|
Consumption(without hard disk and POE): |
| |
≤15 W |
|
Working Temperature: |
| |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
|
Working Humidity: |
| |
10 % ~ 90 % |
|
Chassis: |
| |
380 chassis |
|
Dimensions: |
| |
380 × 290 ×45 mm (15.0"× 11.4" × 1.8") |
|
Weight(without HDD): |
| |
≤ 3 Kg (6.6 lb) |
